650V Enhanced GaN Power Transistor
High Current
High Breakdown Voltage
High Frequency Switching Converter
High Density Converter
650V
| Part Number | RDS(on)(mΩ) | VDS.Max(V) | Qg | Package type | Dimensions(mm) | Datasheet | Spice Model | |
|---|---|---|---|---|---|---|---|---|
 |
FET-E6007PB010 | 65 | 650 | 5.33 | PDFN | 8 * 8 * 0.85 | Contact Us | |
 |
FET-E6007PB020 | 65 | 650 | 5.57 | PDFN | 8 * 8 * 0.85 | Contact Us | |
 |
FET-E6007PD020 | 55 | 650 | 5.02 | PDFN | 8 * 8 * 1.05 | Contact Us | |
 |
FET-E6015PB010 | 123 | 650 | 2.65 | PDFN | 8 * 8 * 0.85 | Contact Us | |
 |
FET-E6015PB020 | 123 | 650 | 2.65 | PDFN | 8 * 8 * 0.85 | Contact Us |
650V
| Part Number | RDS(on)(mΩ) | VDS.Max(V) | Package type | Dimensions(mm) | Datasheet | |
|---|---|---|---|---|---|---|
 |
SIP-P600B040 | 65 | 650 | aQFN | 11.1 * 11.4 * 0.85 | Contact Us |
650V
| Part Number | RDS(on)(mΩ) | VDS.Max(V) | VGS.Max(V) | Qg | Package type | Dimensions(mm) | Datasheet | Spice Model | |
|---|---|---|---|---|---|---|---|---|---|
 |
SOC-S6015ZB020 | 120 | 650 | 16 | 2.7 | PDFN | 8 * 8 * 0.85 | Contact Us | Contact Us |
650V
| Part Number | RDS(on)(mΩ) | VDS.Max(V) | Package type | Dimensions(µm) | Datasheet | |
|---|---|---|---|---|---|---|
 |
GAN-E6012C010 | 119 | 650 | N/A | 3102 * 1175 * 279.4 | Contact Us |
 |
GAN-E6025C010 | 242 | 650 | N/A | 1606 * 1175 * 279.4 | Contact Us |
